| Model | AKJ1530F | AKJ1545F | AKJ1560F | AKJ2030F | AKJ2040F | AKJ2060F | AKJ2560F |
|---|---|---|---|---|---|---|---|
| Cutting Range | 1500*3000mm | 1500*4500mm | 1500*6000mm | 2000*3000mm | 2000*4000mm | 2000*6000mm | 2500*6000mm |
| Laser Power | 1500-40000W | ||||||
| Laser Generator | Raycus/Max/IPG | ||||||
| Control System | Au3tech/Cypcut | ||||||
| Laser Cutting Head | Au3tech/Raytools/Boci | ||||||
| Transmission System | Rack Drive | ||||||
| Rack | VASTUN/Apex/YYC | ||||||
| Guide Rail | HIWIN | ||||||
| Gear Reducer | Motoreducer | ||||||
| Ball Screw | TBI | ||||||
| Servo Motor | Delta/Yaskawa | ||||||
| Electronic Components | Schneider | ||||||
| Pneumatic Components | SMC/AirTAC | ||||||
| Water Chiller | S&A/Hanli | ||||||
| Maximum Moving Speed | 100m/min | ||||||
| Maximum Acceleration | 1.0G | ||||||
| Positioning Accuracy | ±0.01mm | ||||||
| Repeat Positioning Accuracy | ±0.03mm | ||||||
| Voltage and Frequency | 380V 50Hz/60HZ | ||||||
| Comparison Item | Laser Cutting | Plasma Cutting | Waterjet Cutting | Mechanical Cutting |
|---|---|---|---|---|
| Cutting Principle | Focused laser beam melts/vaporizes material | Ionized gas (plasma arc) melts metal | High-pressure water with abrasives erodes material | Physical force using blades/tools |
| Material Compatibility | Metals, some non-metals | Conductive metals only | Almost all materials | Mostly metals and soft materials |
| Cutting Precision | Very high (±0.01–0.05 mm) | Medium (±0.1–0.5 mm) | High (±0.05–0.1 mm) | Low to medium |
| Edge Quality | Smooth, clean, minimal burr | Rougher, requires finishing | Smooth, no heat marks | Often requires deburring |
| Heat-Affected Zone (HAZ) | Very small | Large | None (cold cutting) | None or minimal |
| Cutting Speed | Very fast (especially thin metals) | Fast (thick metals) | Slow to medium | Medium |
| Thickness Capability | Medium to thick (depends on power) | Excellent for thick metals | Excellent for very thick materials | Limited by tool strength |
| Kerf Width | Very narrow | Wider | Medium | Wide |
| Material Deformation | Minimal | Moderate due to heat | None | Possible due to force |
| Automation Capability | Highly automated (CNC/robotic) | Automated | Automated | Semi-automatic or manual |
| Operating Cost | Medium to high (depends on laser type) | Medium | High (abrasives + maintenance) | Low to medium |
| Maintenance Requirements | Moderate (optics, source) | Moderate (consumables) | High (pumps, seals) | Low |
| Environmental Impact | Low emissions, clean process | Produces fumes and gases | No heat, but water disposal needed | Generates chips and noise |
| Noise Level | Low | High | High | Medium |
| Setup Time | Quick | Moderate | Longer setup | Quick |
| Tool Wear | No physical tool wear | Electrode/nozzle wear | Nozzle wear, abrasive usage | High tool wear |
| Ability for Complex Shapes | Excellent (fine details) | Good | Excellent | Limited |
| Secondary Processing Needed | Rarely | Often required | Rarely | Often required |
| Energy Efficiency | High | Medium | Low (high power consumption) | Medium |
| Typical Applications | Precision parts, electronics, automotive | Heavy metal fabrication, shipbuilding | Aerospace, composites, stone cutting | Basic fabrication, construction |
AccTek Laser integrates advanced laser technology into its cutting machines to deliver high precision, stable performance, and efficient cutting results. Their systems use reliable laser sources and optimized control systems, ensuring that operators achieve consistent cuts with minimal material waste. This innovation also helps in enhancing material quality while reducing the risk of thermal damage during the cutting process.
AccTek Laser offers a broad selection of laser cutting machines with different power levels and configurations to suit diverse application requirements. Customers can choose from compact, portable systems for small-scale operations to large industrial machines for high-volume cutting tasks. This makes it easy to find the right solution for cutting metal sheets, plastics, ceramics, and more, ensuring versatility for various industries.
AccTek Laser machines are built using top-quality components sourced from globally recognized suppliers. This includes durable laser sources, cutting-edge scanning systems, and reliable control electronics. By using premium parts, AccTek Laser enhances machine stability, extends service life, and ensures consistent performance under demanding operating conditions, ultimately reducing maintenance needs.
AccTek Laser provides flexible customization options to meet specific customer needs. Machine features like laser power, cutting speed, cooling systems, and automation integration can be tailored to suit different production environments and application requirements. This flexibility ensures that customers achieve optimal cutting performance, productivity, and cost-efficiency.
AccTek Laser offers comprehensive technical support throughout the entire purchase and operation process. Their experienced team assists with machine selection, installation, operation training, and troubleshooting. This level of support helps customers seamlessly adapt to laser cutting technology, ensuring smooth operations and quick issue resolution when necessary.
With years of experience serving customers globally, AccTek Laser provides dependable international service and support. They offer detailed documentation, remote assistance, and responsive after-sales service to help customers maintain their machines and minimize downtime. This ensures that customers can continue their operations with minimal disruptions, enhancing long-term productivity and customer satisfaction.
Learn the key environmental considerations and regulations for CO2 laser cutting machines, including emissions, ventilation, waste management, OSHA, EPA, and global compliance standards.
This article explores the various factors that contribute to the operating costs of laser cutting machines, including energy consumption, materials, labor, maintenance, and technological advancements.
This article mainly discusses how to systematically select a CO2 laser cutting machine suitable for your production scenario, based on key factors such as power, configuration, application requirements, and cost.
This article mainly teaches you how to choose a suitable Chinese brand laser cutting machine. If you are also thinking of getting one, please read this article patiently; you will
The price of a 4000w laser cutting machine varies widely, ranging from $17,000 to $60,000, based on several key factors:
The 4000w laser cutting machine is a significant investment for a business. However, it can also provide significant benefits in terms of increased efficiency, precision, and cost-effectiveness. When choosing a fiber laser cutting machine, you must carefully consider your budget and needs to ensure that you can choose the most suitable machine. You can also contact us, AccTek Laser will recommend the most suitable fiber laser cutting machine for you according to your needs and budget.
The 4000w laser cutting machine is exclusively designed for cutting metal materials, offering a range of advantages that make it an essential tool for various industries:
The machine excels in speed, accuracy, and efficiency, reducing secondary processes like grinding or polishing. It supports high-volume production while maintaining consistent quality, making it indispensable in industries that demand reliability and precision.
The material thickness that a 4000w laser cutting machine can cut depends on several factors, including the type of material, laser source quality, assist gas used, and the cutting speed and precision settings. Here are general guidelines for the maximum thicknesses that can be cut for different materials:
These thicknesses are estimates and may vary based on the laser generator, material quality, and cutting parameters. For optimal results, testing with sample materials and consulting the manufacturer is recommended to determine precise machine capabilities tailored to your specific needs.
The cutting speed of a 4000w laser cutting machine varies based on material type, thickness, laser settings, and the assist gas used. Below are general cutting speeds for common metals:
As material thickness and hardness increase, cutting speeds decrease to preserve edge quality and precision. The 4000w laser cutting machine excels in handling various metal types with faster speeds and greater efficiency compared to lower-powered machines.
The power consumption of a 4000w laser cutting machine can be broken down into the key components that contribute to its overall energy usage. Here’s a detailed breakdown of the estimated power consumption:
The 4000w laser cutting machine requires significantly more power than its nominal cutting capacity, as additional systems like cooling, movement, and air compression contribute to the overall energy usage.
Yes, the 4000w laser cutting machine can typically be customized to meet specific operational needs and preferences. Customization options often depend on the manufacturer, but here are some common ways a 4000w laser-cutting machine can be tailored:
Customization ensures that the 4000w laser cutting machine meets the specific needs of different industries, whether for small-scale workshops or large industrial manufacturers. If you plan to buy a 4000w laser cutting machine, you can contact us at any time. AccTek Laser provides you with a variety of customized configuration options and provides you with detailed and accurate quotes.
The cutting accuracy of a 4000w laser cutting machine is typically high, making it suitable for precision applications across various industries. The key factors contributing to its accuracy include the laser source, cutting head, machine structure, and control systems. Here’s a breakdown of the typical cutting accuracy:
A 4000w laser cutting machine provides high cutting accuracy of ±0.03mm to ±0.05mm, along with excellent repeatability and edge quality. These capabilities make it an excellent choice for industries where precision is critical, such as automotive, aerospace, electronics, and medical device manufacturing.
Our laser cutting machine is backed by a comprehensive warranty designed to give you peace of mind and protect your investment:
Please note that this warranty excludes damage resulting from improper use, mishandling, or other artificial causes.
