| Model | AKQ-1500 | AKQ-2000 | AKQ-3000 | AKQ-6000 |
|---|---|---|---|---|
| Laser Power | 1500W | 2000W | 3000W | 6000W |
| Laser Operating Modes | Continuous Wave Laser | |||
| Laser Generator | Raycus/Max/BWT/JPT | |||
| Laser Wavelength | 1080nm±10nm | |||
| Laser Power Tunability | 10-100% | |||
| Laser Cleaning Head | Au3tech | |||
| Laser Cleaning Width | 10-600mm | |||
| Control System | Au3tech | |||
| Expected Focal Distance | 160mm | |||
| Fiber Cable Length | 10m (JPT:15m) | |||
| Cooling Type | Water Cooling | |||
| Modulation Frequency | ≤20KHz | |||
| Voltage and Frequency | 380V/220V 50/60H | |||
| Working Environment | 10-40℃ | |||
| Operating Humidity | 5-95% | |||
| Comparison Item | Laser Cleaning | Sandblasting | Ultrasonic Cleaning | Dry Ice Blasting |
|---|---|---|---|---|
| Cleaning Principle | Uses focused laser energy to remove rust, paint, oxide, oil, and surface deposits | Uses high-speed abrasive particles to strike and remove contaminants | Uses high-frequency sound waves in liquid to create cavitation bubbles | Uses compressed air to blast dry ice pellets onto the surface |
| Surface Contact | Non-contact cleaning, no mechanical force on the workpiece | Direct impact on the surface with abrasive media | Workpiece must be placed in cleaning liquid | Dry ice pellets impact the surface but sublimate after contact |
| Surface Damage Risk | Low risk when parameters are correctly set | Higher risk of roughening, pitting, or removing base material | Low for many small parts, but unsuitable for some sensitive materials | Lower than sandblasting, but impact force may affect delicate parts |
| Cleaning Precision | Very high; suitable for selective and local cleaning | Lower precision; often cleans a wider area | Good for complex small parts immersed in liquid | Medium precision; better for broad surface cleaning |
| Suitable Materials | Metals, molds, stone, some composites, and selected coated surfaces | Metals, concrete, stone, and heavy-duty surfaces | Small metal, plastic, glass, and precision parts | Metal, rubber, plastic, food equipment, and industrial surfaces |
| Rust Removal | Very effective for light to heavy rust on metal surfaces | Very effective for heavy rust and scale | Limited; better for oil, grease, and fine particles | Moderate; better for dirt, oil, paint, and light residues |
| Paint Removal | Can remove paint layer by layer with controlled parameters | Fast paint removal but may damage the substrate | Not ideal for thick paint removal | Effective for some coatings, but not always for thick or hard paint |
| Oil and Grease Removal | Effective, especially with proper laser settings | Possible but may spread contamination or need extra treatment | Very effective for oil and grease on small parts | Effective for oil and grease without water |
| Cleaning Speed | Fast for targeted areas and automated production lines | Fast for large rough surfaces | Slower because parts need soaking and drying | Fast for large surfaces and production equipment |
| Environmental Impact | No abrasive waste, usually low secondary pollution | Produces dust, spent abrasive, and contaminated waste | Requires cleaning liquid and wastewater treatment | No blasting media residue, but requires CO₂ dry ice supply |
| Consumables | No regular cleaning media required | Requires sand, grit, or other abrasive media | Requires cleaning solution and sometimes additives | Requires dry ice pellets and compressed air |
| Operating Cost | Higher initial cost, lower consumable cost | Lower equipment cost, higher ongoing media and cleanup cost | Moderate cost, depending on tank size and liquid use | Ongoing dry ice and compressed air costs can be high |
| Equipment Investment | Higher initial investment | Usually lower initial investment | Low to medium for small systems; higher for large industrial tanks | Medium to high depending on system size |
| Automation Capability | Excellent; easy to integrate with robots, CNC systems, and production lines | Possible, but media handling and dust control are more complex | Suitable for batch cleaning, less flexible for large parts | Can be automated, but dry ice supply must be managed |
| Cleaning of Complex Shapes | Good for accessible surfaces, corners, welds, and molds | Good for exposed surfaces but may be uneven in narrow areas | Excellent for small complex parts fully immersed in liquid | Good for many shapes, but deep narrow gaps may be difficult |
| Post-Cleaning Treatment | Usually little or no post-cleaning required | Often requires dust removal and surface finishing | Requires rinsing and drying | Usually little residue, but moisture/condensation may need attention |
| Worker Safety | Requires laser safety glasses, enclosure, and fume extraction | Requires dust protection, blasting suit, and hearing protection | Requires chemical handling and liquid safety measures | Requires ventilation, hearing protection, and care with cold materials |
| Noise Level | Relatively low to medium depending on system and extraction | High noise during blasting | Low to medium | High due to compressed air blasting |
| Best Application Scenarios | Precision rust removal, weld cleaning, mold cleaning, oxide removal, coating removal, and automated cleaning | Heavy rust, scale, old coating removal, and rough surface preparation | Small precision parts, medical parts, electronics parts, and oil removal | Food equipment, molds, production lines, and cleaning without water |
| Main Limitation | Higher purchase cost and need for laser safety control | Dust, abrasive waste, surface roughening, and cleanup work | Limited by tank size, liquid use, and drying requirements | Requires dry ice supply, compressed air, and good ventilation |
AccTek Laser uses advanced fiber laser technology to ensure stable performance and precise cleaning results. Their machines provide efficient removal of rust, paint, oil, and coatings while protecting the base material, making them suitable for many industrial cleaning applications.
AccTek Laser offers a variety of laser cleaning machines with different power levels and configurations. Customers can choose from portable handheld machines to high-power industrial systems, allowing businesses to select the most suitable equipment for their specific cleaning tasks.
AccTek Laser machines are built with reliable components such as premium fiber laser sources, high-speed scanning systems, and durable control units. Using quality parts improves system stability, extends machine lifespan, and ensures consistent performance during long-term industrial operation.
AccTek Laser provides flexible customization based on customer needs. Laser power, cooling systems, cleaning width, and automation options can be adjusted according to different applications. This helps businesses achieve optimal cleaning efficiency for various materials and contamination types.
AccTek Laser offers comprehensive technical support, including machine selection guidance, installation assistance, and operation training. Their experienced engineering team helps customers quickly understand the equipment and ensures smooth machine operation after installation.
AccTek Laser serves customers in many countries and provides dependable international service. Detailed documentation, remote technical support, and responsive after-sales service help customers maintain machine performance and minimize downtime during daily production operations.
Is laser dust removal harmful to humans? This guide covers health risks, safety standards, protective measures, and best practices for safe industrial laser dust removal.
This article systematically explains the types and principles of laser cleaning machine cooling systems, daily inspection and maintenance procedures, and methods for diagnosing and handling common faults, helping users quickly
This article will systematically analyze the main limitations of laser cleaning from an engineering and application perspective, and provide mature and practical solutions to help manufacturing companies make informed decisions.
This article delves into the safety operation training requirements for laser cleaning machines in industrial applications, covering laser safety, protective equipment, equipment maintenance, risk management, and compliance standards.
Yes, the price listed is the FOB (Free on Board) price. This means the price covers everything until the product is loaded onto the shipping vessel at the port. After that, the buyer handles all shipping, insurance, and import fees.
The machine offers several power options to suit different cleaning needs. You can choose between 1500W, 2000W, 3000W, and 6000W models. The 1500W option is ideal for lighter cleaning tasks or materials that require a gentler approach. The 2000W and 3000W model provides a stronger cleaning power, making it suitable for medium-duty applications where efficiency and speed are important. The 6000W option offers the highest power, allowing for the most intensive cleaning jobs, and effectively removing heavy rust, coatings, or contaminants from durable surfaces. Each option lets you select the right balance of power, speed, and cleaning intensity based on your specific requirements.
The laser cleaning machine is highly versatile and can clean a wide range of materials. It’s ideal for metals such as steel, aluminum, copper, and brass, effectively removing rust, oxidation, paint, and other contaminants without damaging the base material. It’s also suitable for delicate surfaces like stainless steel, providing a non-abrasive cleaning method that preserves the material’s integrity.
Beyond metals, the laser cleaning machine can work on stone, removing dirt, grime, or paint layers from historical artifacts or statues. It can also clean ceramic surfaces and some types of plastics, depending on their heat sensitivity. This flexibility makes the machine valuable across industries, from manufacturing and automotive to restoration and conservation, where a precise, contactless cleaning process is required.
Our laser cleaning machine offers several cleaning width options to meet different cleaning needs. The standard cleaning width is 270mm, which is ideal for general cleaning tasks and provides efficient coverage. For larger surfaces, you have the option to choose a wider 450mm or 600mm cleaning width, allowing for faster cleaning of bigger areas.
If you require double wobble cleaning for enhanced precision or to cover specific areas, additional options are available. With Double Wobble, you can choose from 130x130mm, 150x150mm, 180x180mm, or 290x290mm, offering a range of sizes for detailed, controlled cleaning. These choices provide flexibility to adapt the machine’s cleaning width to match various tasks and surface areas, ensuring optimal cleaning performance.
Yes, wearing protective glasses is required when using the laser cleaning machine. The laser emits high-intensity light, which can be harmful to your eyes if directly exposed, even from reflected surfaces. Protective laser safety glasses are specifically designed to filter out the laser’s wavelength, providing essential protection to prevent eye damage.
In addition to eye safety, wearing protective glasses is a key part of safe operating practices when working with laser equipment. Even with the machine’s built-in safety features, taking this precaution ensures a safer work environment, particularly in industrial or high-use settings. Always ensure that the protective glasses match the specific wavelength of the laser being used for optimal protection.
Our laser cleaning machine package includes comprehensive technical support options designed to ensure smooth operation and help you maximize machine efficiency. We offer:
Both support options are aimed at helping you achieve the best possible results with your machine. Please let us know if you’d like further details or if you’re interested in arranging on-site training.
Our laser cleaning machine is backed by a comprehensive warranty designed to give you peace of mind and protect your investment:
Please note that this warranty excludes damage resulting from improper use, mishandling, or other artificial causes.
Our laser cleaning machine is certified with internationally recognized standards to ensure quality, safety, and compliance with industry requirements.
If additional certifications are required for specific regions or industries, please let us know, and we can provide further information.
